INDEPENDENT & DEPENDENT 2-POST MOBILITY
Space-saving two-level hydraulic parking platforms designed to instantly double vehicle capacity in residential basements, open driveways, commercial parking bays, and corporate garages without complex civil work.
Space-Saving Two-Level Stack Parking Lifts
2 Cars in 1 Standard Slot
Instantly transform single ground parking slots into double vertical vehicle spaces with an ultra-compact post footprint.
Direct Hydraulic Lifting
High-pressure twin hydraulic cylinders deliver smooth, whisper-quiet platform lifting and lowering in less than 45 seconds.
Dynamic Anti-Fall Safety Latches
Electromagnetic release hooks automatically engage every 100 mm along the columns, locking the upper car safely in place even with zero hydraulic pressure.
2,300 kg to 2,700 kg Rating
High-tensile steel construction engineered to support large SUVs on the upper deck with up to 2,100 mm clear headroom below.
MECHANICAL STACKER PARAMETERS
Stack Parking Lift Technical Parameters
Standard configurations and high-clearance SUV setups built in compliance with BIS standards and international machinery safety codes.
| Specification | Standard Sedan Stacker (2–Post) | Heavy SUV / High–Clearance Setup |
|---|---|---|
| Lifting Capacity (Upper Car) | 2000 kg – 2300 kg (Sedans & Compacts) | 2700 kg – 3200 kg (Full SUVs & Heavy EVs) |
| Usable Platform Width | 2100 mm Standard | 2200 mm – 2400 mm (Wide-Track Vehicles) |
| Lower Car Clearance Height | 1650 mm – 1850 mm (Sedan Clearance) | 2050 mm – 2150 mm (Full-Size SUV Clearance) |
| Lifting / Lowering Speed | Lifting: ~45 sec | Lowering: ~35 sec | Lifting: ~50 sec | Lowering: ~40 sec |
| Drive Mechanism | Direct-Drive Twin Hydraulic Cylinders | Heavy Hydraulic Ram + Balance Steel Chain |
| Power Supply & Motor | 2.2 kW | Single Phase 230V / 3-Phase 415V | 2.2 kW – 3.7 kW | 3-Phase 415V, 50Hz |
| Operating Control | Key Switch Console / Push Button Box | Key Switch Console + Emergency Stop + RFID Card |
| Fall Protection & Safety | Mechanical Multi-Position Safety Locks | Dynamic Anti-Fall Wedge Locks + Photoelectric Grid |
| Safety Compliance | BIS Standards & CE Machinery Certified | Full-Height Optical Sensor + Overload Cutoff |
STACKER PLATFORM ENGINEERING
Corrosion Protection & Operator Safety
Engineered with high-tensile galvanized decks, enclosed posts, and automatic optical shut-off sensors.
ZERO RUST
Hot-Dip Galvanized Waved Pallet
Continuous hot-dip zinc plating shields steel platforms from water, snow, and engine oil leaks, paired with tire stop baffles to prevent vehicle rollover.
COLLISION PREVENTION
Photoelectric Light Barrier
Optical infrared beam sensors monitor the lower parking bay, instantly halting lift descent if a car, pet, or human enters the area.
SECURE OPERATION
Dead-Man Control Console
Easy-to-reach operator arm requiring a continuous key-turn to operate, ensuring the user maintains full visual line-of-sight during the entire lift cycle.
ARCHITECTS, BUILDERS & GARAGE MANAGERS
Check Your Basement Clear Ceiling Height Feasibility
Send us your ceiling beam clearance and column distances. Our technical team will evaluate your layout and confirm whether a 3.2m (Sedan/Sedan) or 3.6m+ (SUV/Sedan) stacker fits without civil structural modification.
- Clear Ceiling: From 3100 mm
- No Concrete Pit Required
- Single / 3-Phase Power Ready
